Onwa KP-6299

Piyasa Fiyatı :

Site Fiyatı : Sorunuz

Kredi Kartı ile Tek Çekim : Sorunuz TL

Havale ile İndirimli : Sorunuz TL

TIKLA WHATSAPP İLE SİPARİŞ VER

05374116060

7x24 Whatsapp Üzerinden de Sipariş Verebilirsiniz.

Sepete ekle

Hemen Satın Al

Yorumları oku (0)

( Karşılaştır )

Açıklama
Ödeme Bilgileri
Video
Ürün Yorumları
SSS

5.7 " Renkli LCD GPS Plotter / C-Map MAX ile uyumlu

Yüksek çözünürlüklü TFT day view LCD ekran
C-Map MAX için SD kart yuvası ve kullanıcı verileri
C-Map MAX ve K-Chart seçilebilir
Gelgit tablosu
Çok Yönlü Görüntüleme Modu

Plotter Ekranı
Nav.Data
Uydu Bilgisi
AIS Ekran
Pusula Ekranı

GOTO track navigasyon
Harita yönlendirmesi seç
Yakınlık yol işaretleri alarmları
Perspektif görünüş
Palet

Normal
Gün ışığı - Güneş ışığına maruz kalma
Gece - karanlık ortamlarda
NOAA - kağıt grafik renkleri

ÖZELLİKLER

PLOTTER CHARACTERISTICS
1. Waypoints/icons	15,000 waypoints with name, symbol, 10 proximity waypoint
2. Routes	waypoint up to 200 points each, plus MOB and Track Navigation or Goto Track modes
3. Tracks	30,000 point automatic track log; 15 saved track (up to 2000 track points each) let you retrace your path in both directions
4. Alarms	XTE, Anchor drag, arrival, speed, voltage, proximity waypoint and time, AIS alarm.
5. Pallete	Normal Daylight exposed to sunlight Night in dark environment NOAA paperchart colors
6. Tides	Tide data
7. Projection	Mercator projection
8. Position format	Lat/Lon
9. Basemap	Built-in Onwa K-Chart
10. External Map	SD Cards slot for C-Map MAX
11. User data storage	Internal backup of user settings, or external SD-card
12. Plot Interval	1s to 99h or 0.01 nm to 9.99nm
13. Plotting scales	0.01nm to 1,000nm
14. Nav Data	Inputs: $–DBT, $–DPT, $–GGA, $–GLL,$–GSA, $–GSV, $–HDG,$–HDM,$–HDT,$–MTW, $–RMB,$–RMC, $–VTG, $–ZDA, $–VWR,$–VWT,$–MWD, $–VPW Outputs: $–AAM, $–APB, $–BOD,$–BWC,$–GGA, $–GLL, $–RMB,$–RMC,$–VTG, $–XTE, $–ZDA Outputs for autopilot: $–AAM, $–APB, $–BOD,$–VTG
15. Perspective View	On/off

POWER SUPPLY	10.5 to 35VDC, current drain

PHYSICAL
1. Size	228mm(H)X138mm(W)X79mm(D)
2. Weight	0.9kg
3. Display	5.6-inches ColorTFT day-view LCD 640 X 480 pixels
4. Waterproofing	Display unit: IPX5 Antenna unit: IPX6
5. Temperature range	Display unit: -15℃ to +55℃ Antenna unit: -25℃ to +70℃

GPS RECEIVER CHARACTERISTICS
1. Receiver	12 parallel channel GPS receiver continuously Tracks and uses up to 12 satellites to compute and update your position
2. Acquisition times	Cold start: 60 seconds average Warm start: 45 seconds average Hot start: 15 seconds average
3. Update rate	1/second,continuous
4. Accuracy	Position: Velocity: 0.1 Meter/sec without S/A Time: ±100ns synchronized to GPS time
5. Dynamics	Altitude: 18,000m Max Velocity: 500 m/s Acceleration: 4g Max
6. Datum	WGS 84 & Others
7. Interfaces	NMEA 0183 input and output,RS232 and RS422 output
8. Antenna	KA07

AIS INTERFACE
1. Data input	NMEA 0183 , R8232
2. Baud rate	38400 and 4800

EQUIPMENT LIST
Display unit Antenna unit with 10m cable Operation manual Installation materials and standard spare parts
