F700

Wide 7" Color Fishfinder

 Fast screen response by high performance CPU

 Suitable for small fishing boat

 Easy to distinguish fish on bottom by digital enlargement

 Reinforce fish detection by auto pulse

 Detect fish by high data transmission

 Easy to use by auto gain

Features

• Fast screen response by high performance CPU

• Suitable for small fishing boat

• Easy to distinguish fish on bottom by digital enlargement

• Reinforce fish detection by auto pulse

• Detect fish by high data transmission

• Easy to use by auto gain

Specifications

• Size : 171 mm(H) x 205 mm(W) x 75 mm(D)

• Dispaly : Wide 7”, TFT color, 800 x 480 pixels

• Supply voltage : 10 to 34 V DC

• Supply current : 13.8 V, 0.8A min - no backlighting. 1A max - full backlighting.

• Operating temp.: -10℃ ~ 50℃

• Alarms: Arrival radius, anchor, XTE, danger, too shallow, too deep, fish, temperature, temperature   rate, low battery,

low fuel(optional), loss of DGPS fix, radar guard zone, dangerous AIS vessels.

• Frequency : 50/200KHz

• Output : 600W

• Depth Range : Min : 0m~3m, Max : 0m~1,500m

• Color Display : 16 colors

• Brightness : 10-step

• Screen Moving Speed : super fast, fast, medium, low, stop

• Battery Voltage Display : Voltage number dispaly

• AUTO GAIN adjustment : OFF/ON

• A-Mode display : OFF/ON

• Demo dispaly : OFF/ON

• Weak Color Removal : 0%~75%
